HT500Y-4 Excavator

Power model

Engine Model Briggs&Stratton Pioneer

Power type

Engine Type Single cylinder, OHV, 4-stroke, air cooling

Total displacement (ML)

displacement 203CC

Rated power (kw/rpm)

Rated Power 6.5HP/3600rpm

Fuel Type

92 # Gasoline

Fuel Tank Capacity (L)

3.6

Body weight (KG)

Total Weight 550

Maximum load (KG)

Maximum load 500

Body size (MM)

Machine size (Without foot, without bucket)

1570 * 880 * 1450

Bucket size with foot pedal

2050 * 880 * 1450

Container size (MM)

1050 * 730 * 730

Chassis width (MM)

700

Maximum rise (MM)

1020mm

Tipping height (MM)

970mm

Tipping interval (MM)

220mm

Track width (MM)

track width 180

Track grounding length (MM)

1000

Chassis ground clearance (MM)

110

Container capacity (DM) ³

Cargo Box Capacity 200

Tipping System

Hydraulic Tipper

Tilting Angle

100

Walking speed

2.88 km/h

Minimum Turning radius (MM)

1150

Track gauge

520

Climbing ability (°)

Climbing ability 2
