HT500Y-5 Excavator

Power model

420

Power type

air-cooled four-stroke gasoline engine, OHV

Total displacement (ML)

420CC

Rated power (kw/rpm)

13.5HP/3600rpm

Fuel type

92 # Gasoline

Fuel consumption (g/w·h)

≤ 0.7

Fuel tank capacity (L)

6.5

Oil capacity (L)

1.1

Body weight (KG)

880

Maximum load capacity for horizontal transportation (KG)

1000

Maximum lifting and unloading load (KG)

550

Body size (MM)

Excluding foot pedal and bucket

1800 * 880 * 1920

Bucket size with foot pedal (MM)

2700 * 880 * 1920

Box size (MM)

1220 * 800 * 600

Chassis width (MM)

850

Maximum lifting and unloading height (MM)

1500

Overturning distance (MM) 350

Track width (MM)

180

Track grounding length (MM)

915

Chassis ground clearance (MM)

100

Container capacity (DM) ³

two hundred and ninety

Tipping System Hydraulic Tipper

Flipper angle (°)

100

Walking performance speed (km/h)

3

Minimum turning radius (m)

1300

Track center distance (mm)

670

Chassis ground clearance (mm)

100

Climbing ability (°)

25

Hydraulic oil tank capacity (L)

12 (with radiator attached)
